AT-iMG646MOD Installation Guide
35
Appendix A
Technical Specifications
Orderable Parts
Go to www.alliedtelesis.com, along the top menu banner select Products, along
the side menu select CPE Gateways, and then RESIDENTIAL GATEWAYS. The
tabs include supporting documentation.
Physical Specifications (iMG646MOD)
Dimensions: AT-EN646MOD 330 mm x 230.7 mm x 43.2 mm
(13 in x 9.1 in x 1.7 in)
AT-iMG646MOD 222 mm x 222 mm x 25 mm
(8.75 in x 8.75 in x 1.0 in)
Weight: AT-EN646MOD 1.2 kg (3 lbs)
AT-iMG646MOD (max) 1.3 kg (2.7 lbs)
Physical Specifications (iMG626MOD)
Dimensions: AT-EN646MOD 330 mm x 230.7 mm x 43.2 mm
(13 in x 9.1 in x 1.7 in)
AT-iMG626MOD 222 mm x 222 mm x 25 mm
(8.75 in x 8.75 in x 1.0 in)
Weight: AT-EN646MOD 1.2 kg (3 lbs)
AT-iMG626MOD (max) 1.3 kg (2.7 lbs)
Note
The iMG626MOD is used in the same enclosure and has the same
dimensions as the iMG646MOD, but has only two RJ11 telephone
connections.
