34 Chapter 5: Turn-Up and Troubleshooting
Problem: There is a problem with the telephone service.
Solution: Check the following:
ˆ Swap out the cable for a known good cable.
ˆ For POTS phones and fax machines, verify that the dial mode for the telephone and fax are correct,
according to the manual that was supplied with the telephone or fax.
ˆ Check the telephone or fax machine for problems.
Note
If you need further assistance, please contact Allied Telesis Technical Support. Refer to “Contacting
Allied Telesis” on page 8.
Understanding the LEDs (T1/E1 Card)
Figure 26. LEDs for AT-iMG646MOD
Table 3. LEDs and Meanings - To Be Supplied
LED Meanings
NETWORK ON -
OFF -
LINK ON -
OFF -
ADMIN ON -
OFF -
2, 1 Separate DS1/T1 links.
NETWORK
LINK
2 1
ADMIN
NETWORK
LINK
ADMIN
T1_DS1_LEDs.ai
