Page 29
AT-iMG646MOD Installation Guide
Chapter 4: Installing the Gateway Indoors
29
Connecting the Telephone Wires
To connect the telephone wires, simply connect each phone line directly into the RJ-11 ports on the AT-
iMG646MOD.
Connecting the LAN Cables
To connect the LAN cables, perform the following procedure:
Note
Allied Telesis recommends that you fully wire all six ports to allow for easy service expansion in the
future.
Note
Do not connect the Ethernet cables to the unit until the unit has completed its bootup sequence. This
may take several minutes if network software upgrades are needed.
1. Connect the LAN cables to the RJ-45 ports on the gateway, as shown in Figure 24
.
Figure 24. Connecting the LAN Cables
