58 SwitchBlade 4000 Series Switch
C613-03060-00 REV H
Port, Connector, and Cable Combinations
This section provides cabling guidelines for each line card model.
1. Refer to the IEEE 802.3 standards for further cable information.
2. Assumes a fibre optic cable rating of 500 Mhz/Km. (Maximum cable length is 500m at a cable rating of 400 Mhz/Km.)
3. Assumes a fibre optic cable rating of 200 Mhz/Km. (Maximum cable length is 220m at a cable rating of160 Mhz/Km.)
Table 18: Cable guidelines for line cards.
Model Port Type Connector Type Cable Type
1
Maximum Cable Length
AT-SB4311
Line Card 10BASE-T/100BASE-TX RJ-45 10BASE-T Category 3 or
better
100BASE-TX Category 5
or better
100m (328ft)
100m (328ft)
AT-SB4352
line card 100BASE-FX MT-RJ 50/125 or 62.5/125
micron multimode fibre Full-duplex 2km (6,600ft)
Half-duplex 412m
(1360ft)
AT-SB4411
Line Card 10BASE-T/100BASE-TX/
1000BASE-T RJ-45 CAT5
CAT5E
100 to 150m
(328 to 492ft)
200m (656ft)
AT-SB4412
Line Card 10BASE-T/100BASE-TX/
1000BASE-T RJ-45 CAT5
CAT5E
100 to 150m
(328 to 492ft)
200m (656ft)
AT-SB4441
Line Card 1000BASE-X Varies with GBIC Refer to GBIC’s user
documentation Refer to GBIC’s user
documentation
AT-SB4451
Line Card 1000BASE-SX SC 50/125 micron
multimode fibre
62.5/125 micron
multimode fibre
550m (1,804ft)
2
275m (902ft)
3
AT-SB4452
Line Card 1000BASE-SX MT-RJ 50/125 micron
multimode fibre
62.5/125 micron
multimode fibre
550m (1,804ft)
2
275m (902ft)
3
AT-SB4461
Line Card 1000BASE-LX SC 9/125 micron
singlemode fibre
50/125 or 62.5/125
micron multimode fibre
3km (1.8mi)
Increasing to 10km (6mi) if
linking two 1000BASE-LX
models
550m (1804ft)
2
AT-SB4462
Line Card 1000BASE-LX MT-RJ 9/125 micron
singlemode fibre
50/125 or 62.5/125
micron multimode fibre
3km (1.8mi)
Increasing to 10km (6mi) if
linking two 1000BASE-LX
models
550m (1804ft)
2
