46 SwitchBlade 4000 Series Switch
C613-03060-00 REV H
Figure 6: Example output from the SHOW TEST INT command on an AT-SB4411 with ports 3.1 and 3.2 linked by
a crossover cable.
Figure 7: Example output for the SHOW TEST COUNT command.
Other Interface Tests
Refer to the Test Facility of the SwitchBlade Software Reference for information on
testing other interfaces.
If a test fails, please contact your authorised Allied Telesis distributor or reseller.
Board ID Bay Board Name Rev Serial number
----------------------------------------------------------------------------
Base 164 AT-SB4411 M1-0 50433214
Duration Details
Interface State Result Type (minutes) Data( %OK ) Control
----------------------------------------------------------------------------
eth0 testing wait 4 minutes trans 0 - - -
TP < 1 BAD ( 0.0) -
ENDEC 0 - - -
MAC < 1 good(100.0) - .
port3.1 testing wait 4 minutes TP < 1 good(100.0) - .
port3.2 testing wait 4 minutes TP < 1 good(100.0) - .
port3.3 no test - - - - - -
port3.4 no test - - - - - -
port3.5 no test - - - - - -
port3.6 no test - - - - - -
port3.7 no test - - - - - -
port3.8 no test - - - - - -
Board ID Bay Board Name Rev Serial number
----------------------------------------------------------------------------
Base 164 AT-SB4411 M1-0 50433214
Duration Frame Counters
Interface State Type (minutes) Tx RxTotal RxGood RxBad
--------------------------------------------------------------------------------
eth0 testing trans 0 000000000 000000000 000000000 000000000
TP < 1 000000047 000000046 000000000 000000046
ENDEC 0 000000000 000000000 000000000 000000000
MAC 0 000000000 000000000 000000000 000000000
port3.1 testing TP < 1 000114290 000114289 000114289 000000000
port3.2 testing TP < 1 000114290 000114289 000114289 000000000
port3.3 no test - - - - - -
port3.4 no test - - - - - -
port3.5 no test - - - - - -
port3.6 no test - - - - - -
port3.7 no test - - - - - -
port3.8 no test - - - - - -
