56 SwitchBlade 4000 Series Switch
C613-03060-00 REV H
Gigabit Interface Converters (GBICs)
The AT-SB4441 line card provides ports for eight GBICs. These are small
hot-swappable plug-in transceivers. By selecting the appropriate GBIC type,
you can match your SwitchBlade ports to their appropriate network interface.
RJ-45 copper, SC and LC fibre GBICs are currently available.
GBIC 1000BASE-T Auto-Negotiation
The 1000BASE-T GBICs operating in the AT-SB4441 line card will provide only
1000 Mbps full-duplex connections. Although these GBICs will participate in
auto-negotiation processes, they will only advertise 1000 Mbps. Half duplex,
10BASE-T, and 100BASE-TX modes are not supported.
While 1000BASE-T GBICs will auto-negotiate at the copper Ethernet level, the
ports will behave as if in fixed 1000 Mbps full-duplex mode. This is because the
SERDES connection used by GBIC ports makes the auto-negotiation invisible
to the switch, and so prevents a successful link negotiation.
The following Allied Telesis GBIC transceivers can be ordered from your
authorisedAllied Telesis reseller.
Small Form Factor Pluggables (SFPs)
The AT-SB4442 line card provides ports for 24 SFPs. SFPs are miniature
hot-swappable plug-in transceivers. By selecting the appropriate SFP type, 1
Gbps ports can be matched to the appropriate network interface, RJ-45 copper
or LC fibre. The following Allied Telesis SFP transceivers can be ordered from
your Allied Telesis reseller:
Model Media Type Description
AT-G8T 1000BASE-T Copper, 100m at 1000Mbps
AT-G8SX-01 1000BASE-X 550m SX, 50µm MM fibre
220m SX, 62.5µm MM fibre
AT-G8LX10 1000BASE-X 10 km LX, 9µm SM fibre
AT-G8LX25 1000BASE-X 25 km, LX, 9µm SM fibre
AT-G8LX40 1000BASE-X 40 km, LX, 9µm SM fibre
AT-G8LX70 1000BASE-X 70 km, LX, 9µm SM fibre
AT-G8ZX70/wwww
1
where xxxx is:
1610, 1590, 1570,
1550, 1530, 1510,
1490, 1470, 1450,
1430, 1410, 1390,
1370, 1350, 1330,
1310
1. Both ends of an individual fibre must use GBICs of the same wavelength.
1000BASE-ZX CWDM 1610nm to 1310nm (20nm intervals),
70 km, ZX, 9µm SM fibre
Model Media Type Description
AT-SPTX 10/100/1000BASE-T Copper, 100m at 1000Mbps, RJ-45 connector
