Hardware Reference 15
C613-03060-00 REV H
#
add vlan="v2" port=2.1-2.4
#
# vlan swapped out configuration
add vlan="v2" port=1.1-1.8
After the new line card is inserted and the create config command is
entered, the show config dynamic command displays the following
configuration:
#
# vlan configuration
#
add vlan="v2" port=2.1-2.4
7. (continuing from the end of Example 4) The wrong line card is accidentally
inserted into slot 1. The user realises the mistake and removes the line card.
The user has also already made further configuration changes, and saves
the configuration by using the command:
create config
Because the line card that was inserted by accident has been hot swapped,
creating a configuration removes the commands stored in the swapped-out
configuration. When the correct line card is inserted, it is initialised without
configuration.
To avoid loss of the swapped-out configuration in this situation, insert the
correct line card, and restart the SwitchBlade. Then make the other
configuration changes and create the configuration.
Physical and Operating Specifications
This section provides an overview of the SwitchBlade’s physical and operating
specifications.
AT-SB4108 SwitchBlade 8 Card Chassis
Dimensions
• Height: 666 mm (15U rack occupancy)
• Width: 440 mm (excluding rack-mounting brackets). Suitable for 19
inch racks
• Depth: 392.5 mm (539 mm if a cable manager is attached)
• Chassis 8 weight: 19 kg (empty chassis)
• Chassis 8 loaded Weight: 34 to 63.5 kg (depending on the configuration)
Environmental Conditions
• Operating temperature range: 0 to 40º C (32 to 104º F)
• Storage temperature range: -25 to 70º C (-13 to 158º F)
• Relative humidity range: 5 to 95% non-condensing
