Allied Telesis
AT-S95 Management Software Web Browser Interface User’s Guide
LLDP MED Power over Ethernet
The port PoE information.
• Power Type — Indicates the power type advertised on the port.
• Power Source — Indicates the power source advertised on the port.
• Power Priority — Indicates the port’s power priority advertised on the port.
• Power Value — Indicates the port’s power value, in Watts advertised on the port.
Inventory
•
Hardware Revision — Displays the hardware version number.
• Firmware Revision — Displays the firmware version number.
• Software Revision —Displays the software version number.
• Serial Number — Displays the device serial number.
• Model Name — Displays the device model name.
• Asset ID — Displays the device asset ID.
LLDP MED Network Policy
•
Application Types — Indicates the port’s LLDP Network Policy for each of the following:
– Voice
– Voice Signaling
– Guest VLAN
– Guest VLAN Signaling
– Softphone Voice
– Video Conferencing
– Streaming Video
– Video Signaling
• Flags — Displays the VLAN tagging status for the application type. The possible field values are:
– Tagged — The packets are tagged.
– Untagged — The packets are not tagged.
• VLAN ID — Displays the VLAN ID attached to the LLDP-MED network policy.
• User Priority — Displays the User Priority attached to the LLDP-MED network policy.
• DSCP — Displays the DSCP value attached to the LLDP-MED network policy. The possible field value is
0-63.
LLDP MED Location
•
Location Type — The port’s advertised LLDP-MED location of the following:
– Coordinates — Displays the device’s location map coordinates.
– Civic Address — Displays the device’s civic or street address location, for example 414 23rd Ave E. The
possible field value are 6 - 160 bytes.
– ECS ELIN — Displays the device’s ECS ELIN location. The field range is 10 - 25 bytes.
• Location Address — The location as described.
3. Select the port for which you want to see the LLDP MED neighbors information details.
