Chapter 2: System Configuration
40
IP Access List Configuration
When the IP Access List feature is enabled, remote access to the
AT-S114 management software is restricted to the IP addresses entered
into the IP Access List.
The procedures in this section describe how to enable or disable the IP
Access List feature and how to add or remove IP addresses from the list.
See the following sections:
 "Create an IP Access List"
 “Delete an IP Address List Entry” on page 41
Note
To modify an IP address that has already been created, it must first
be deleted and then re-created using the following procedures.
Create an IP
Access List
To create a list of accessible IP addresses, perform the following
procedure:
1. From the main menu on the left side of the page, click the System
folder.
The System folder expands.
2. From the System folder, select IP Access List. The IP Access List
Page is displayed. See Figure 13.
.
Figure 13. IP Access List Page
