AT-2973SX, AT-2973T, AT-2973T/4, and AT-VNC10S Adapters Installation and User’s Guide
35
Replacing the Bracket
The AT-2973SX, AT-2973T, AT-VNC10S adapters are shipped with the
low-profile bracket attached to the adapter. In addition, the standard
bracket is included in the shipment. Depending on your PC, you may need
to replace the bracket attached to your adapter.
Note
The AT-2973T/4 adapter is shipped with a standard bracket
attached to the card. A low-profile bracket is not included with this
adapter.
The following procedure describes how to remove the low-profile bracket
from the adapter and replace it with the standard bracket. You can also
use this procedure to remove the standard bracket and replace it with the
low-profile bracket.
To replace the low-profile bracket with the standard bracket, do the
following:
1. Remove the screws that attach the bracket to the adapter. See
Figure 9.
Figure 9. Removing the Low-Profile Bracket
