97
Appendix A
Technical Specifications
This section contains the following product technical specifications:
 ”Physical Specifications” on page 97
 ”Environmental Specifications” on page 99
 ”PoE Power Specifications” on page 100
 ”Power Specifications” on page 100
 ”Certifications” on page 102
 ”RJ-45 Twisted Pair Port Pinouts” on page 102
 ”Fiber Optic Port Specifications” on page 104
 ”RJ-45 Style Serial Console Port Pinouts” on page 106
Physical Specifications
Dimensions (H x W x D)
Table 16. Product Dimensions
Model Dimensions
AT-FS970M/8
AT-FS970M/8PS
AT-FS970M/8PS-E
AT-FS970M/24C 33.0 cm x 20.3 cm x 4.4 cm
(13.0 in. x 8.1 in. x 1.7 in.)
AT-FS970M/48
AT-FS970M/24F 44.1 cm x 29.1 cm x 4.4 cm
(17.3 in. x 11.5 in. x 1.7 in.)
AT-FS970M/24LPS
AT-FS970M/24PS
AT-FS970M/48PS
AT-FS970M/16F8-LC
AT-FS970M/16F8-SC 44.1 cm x 32.2 cm x 4.4 cm
(17.3 in. x 12.7 in. x 1.7 in.)
