Overview
24
Fiber Optic Switch
The FS970M Series has two fiber optic switches, the AT-FS970M/16F8-
LC and AT-FS970M/16F8-SC.
Hardware
Features
Table 3 lists the hardware features of the fiber optic switch.
Table 3. Hardware Features of the AT-FS970M/16F8-LC Fiber Optic Switch
Feature 16F8-LC 16F8-SC 24F
Number of 100Base-FX Fiber Optic Ports 16 16 24
Connectors Duplex LC Duplex SC Duplex LC
Maximum Distance per Port 2 kilometers
(1.24 miles)
2 kilometers
(1.24 miles)
2 kilometers
(1.24 miles)
Number of 10/100Base-TX Ports 8 8 8
Number of 10/100/1000Base-T Ports 2 2 2
Number of SFP Slots for 100Mbps 100Base-FX
or 1000Mbps 1000Base-SX/LX Transceivers
1
2 2 2
Power over Ethernet No No No
Number of Power Supplies 2 2 2
Power Supply Type AC AC AC
Console Management Port Yes Yes Yes
Ventilation Fan Yes Yes Yes
1. The SFP transceiver slots and the 10/100/1000Base-T ports are paired together to form combo ports, as
explained in “SFP Slots” on page 37.
