Back panels – Allied Telesis FS970M Series User Manual
Page 28
Overview
28
Back Panels
Figure 8 shows the back panels of the single power supply switches.
Figure 8. Back Panels of the Single Power Supply Switches
AC Power
Connector
AT-FS970M/8, AT-FS970M/8-E, and AT-FS970M/24C Switches
AC Power
Connector
AT-FS970M/8PS Switch
AT-FS970M/24LPS and AT-FS970M/48 Switches
