Beginning the Installation

60

The AT-FS970M/24PS, AT-FS970M/24F, AT-FS970M/48PS,
AT-FS970M/16F8-LC, and AT-FS970M/16F8-SC Switches come with the
components listed in Figure 19.

Figure 19. Components of the AT-FS970M/24PS, AT-FS970M/24F,

AT-FS970M/48PS, AT-FS970M/16F8-LC, and AT-FS970M/16F8-SC

Switches

Two rack mounting brackets

One 2 m (6.6 ft) local management cable with
RJ-45 (8P8C) and DB-9 (D-sub 9-pin)
connectors.

Eight bracket screws

Two regional AC power cords
