Allied Telesis FS970M Series User Manual
Page 29
FS970M Series Installation Guide
29
Figure 9 shows the back panel of the dual power supply switches
including:
AT-FS970M/16F8-LC
AT-FS970M/16F8-SC
AT-FS970M/24F
AT-FS970M/24PS
AT-FS970M/48PS
Figure 9. Back Panel of the Dual Power Supply Switches
AC Power
Connector
AC Power
Connector
(Power Supply 2)
(Power Supply 1)
Switches
