FS970M Series Installation Guide
25
Front Panel The front panel of the AT-FS970M/16F8-LC Switch is shown in Figure 5.
Figure 5. Front Panel of the AT-FS970M/16F8-LC Fiber Optic Switch
The front panel of the AT-FS970M/16F8-SC Switch is shown in Figure 6.
Figure 6. Front Panel of the AT-FS970M/16F8-SC Fiber Optic Switch
AT-FS970M/16F8-LC
100Base-FX Fiber
Combo
Ports and SFP Slots
Optic Ports with
10/100Base-TX
Twisted Pair
Duplex LC Connectors
Ports
10/100/1000Base-T
Management
Panel
AT-FS970M/16F8-SC
100Base-FX Fiber
Combo
Ports and SFP Slots
Optic Ports with
10/100Base-TX
Twisted Pair
Duplex SC Connectors Ports
10/100/1000Base-T
Management
Panel
