Front Panels The front panels of the 8-port switches are shown in Figure 1.
Figure 1. Front Panels of the 8-port FS970M Switches
Front Panel
Components
Figure 2 identifies the Fast and Gigabit Ethernet networking ports and the
SFP slots on the 8-port switches.
Figure 2. Networking Ports and SFP Slots on the 8-port Switches
AT-FS970M/8
AT-FS970M/8PS
AT-FS970M/8PS-E
10/100Base-TX
Combo 10/100/1000Base-T
Ports and SFP Slots
Ports
Management
Panel
