78

Chapter 3

Removing the LCD Bezel

1. See “Removing the LCD Module” on page 55.
2. Remove the two upper and two lower bezel screw caps and screws.

3. Starting from the bottom edge of the bezel, pry the bezel upwards and away from the panel. Work along the

right side toward the top of the bezel, prying the covers apart. Continue along the top edge and down the left

side to remove the bezel.

NOTE: If necessary, use a pry to lift up the outside edges of the bezel.

Step

Size

Quantity

Screw Type

LCD Bezel

M2.5*6

4
