Indicators

The computer has several easy-to-read status indicators. The front panel indicators are visible even when the

computer cover is closed.

NOTE: 1. Charging: The light shows amber when the battery is charging. 2. Fully charged: The light shows

green when in AC mode.

No.

Icon

Item

Description

1

Battery bay

Houses the computer's battery pack.

2

Battery release

latch

Releases the battery for removal.

3

Battery lock

Locks the battery in position.

4

Hard disk bay

Houses the computer's hard disk (secured with

screws).

5

Memory

compartment

Houses the computer's main memory.

5

Ventilation slots

and cooling fan

Enable the computer to stay cool, even after

prolonged use.
Note: Do not cover or obstruct the fan opening.

Icon

Function

Description

Num Lock

Lights up when Num Lock is activated.

Caps Lock

Lights up when Caps Lock is activated.
