Lcd module disassembly process, Lcd module disassembly flowchart – Acer 5241 User Manual
Page 87
Chapter 3
77
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Step
Screw
Quantity
Part No.
LCD Bezel
M2.5*6
4
86.N2802.002
LCD Panel
M2.5*6
2
86.N2802.002
LCD Brackets
M2*3
6
86.N2802.004
Remove
LCD Panel
Remove
LCD Bezel
Remove
LCD FPC Cable
Remove LCD
Panel from Main
Unit before
proceeding
Remove
LCD Brackets
Remove
Antennas
Remove
Camera Module
