Display Option Description
Notes
dynamic parameter #12. (see section 3.4.4).
IsotopeRatio
Isotope ratio (‰) calculated from concentrations for ramp A and ramp B. Note that if
Rstandard is set to zero, then the isotope ratio is set to zero.
2
Mean Ratio
Isotope ratio (‰), calculated from mean concentration for ramp A and ramp B
2
Ratio StDev
Standard deviation of the isotope ratio (‰), where the averaging period is specified by
dynamic parameter #12 (see section 3.4.4).
2
RampB Offset
Ramp B Offset Current (mA)
2
TGA Analog 1
TGA Analog Channel 1 voltage (V)
TGA Analog 2
TGA Analog Channel 1 voltage (V)
TGA Analog 3
TGA Analog Channel 1 voltage (V)
PC Analog 1
PC Analog Channel 1 voltage (V)
PC Analog 2
PC Analog Channel 2 voltage (V)
PC Analog 3
PC Analog Channel 3 voltage (V)
PC Analog 4
PC Analog Channel 4 voltage (V)
PC Analog 5
PC Analog Channel 5 voltage (V)
PC Analog 6
PC Analog Channel 6 voltage (V)
PC Analog 7
PC Analog Channel 7 voltage (V)
PC Analog 8
PC Analog Channel 8 voltage (V)
Ux, m/s
CSAT3 wind speed component U
x
(m s
-1
) 3
Uy, m/s
CSAT3 wind speed component U
y
(m s
-1
) 3
Uz, m/s
CSAT3 wind speed component U
z
(m s
-1
) 3
T_Sonic, deg
CSAT3 sonic temperature (°C)
3
Diagnostic W
CSAT3 diagnostic word
3
Other Dev 1
CR9000 data value 1
4
Other Dev 2
CR9000 data value 2
4
Other Dev 3
CR9000 data value 3
4
Other Dev 4
CR9000 data value 4
4
Other Dev 5
CR9000 data value 5
4
Other Dev 6
CR9000 data value 6
4
Other Dev 7
CR9000 data value 7
4
Other Dev 8
CR9000 data value 8
4
Other Dev 9
CR9000 data value 9
4
Other Dev 10
CR9000 data value 10
4
Other Dev 11
CR9000 data value 11
4
Other Dev 12
CR9000 data value 12
4
Other Dev 13
CR9000 data value 13
4
Other Dev 14
CR9000 data value 14
4
Other Dev 15
CR9000 data value 15
4
M/S 1 Conc
Trace gas concentration (ppm) of TGA slave #1
1, 5
M/S 2 Conc
Trace gas concentration (ppm) of TGA slave #2
1, 5
