CS650 and CS655 Water Content Reflectometers

6.6.6 CR200X With 3 CS650 Probes

This CRBasic example program measures 3 CS650 probe on a CR200X every

15 minutes, storing hourly averages of volumetric water content, electrical

conductivity, soil temperature, permittivity, period average, and voltage ratio.

The CS650’s have SDI-12 addresses of 0, 1, and 2. Sensors are powered with

the SWBatt channel which requires a 3 second warm-up time. Alternately, the

red wires may be connected to Battery + for continuous power which would

reduce measurement time. Wiring for the example is shown in TABLE 6-10.

Assignment of aliases and units is not shown in this example but may be used

following Program Example 1 above.

TABLE 6-10. Wiring For Program Example 6

CR200X

CS650’s (Wiring same for all)

SW Battery Red
C1/SDI-12

Green

G channels

Black, Orange, Clear

Code Example 6. CRBasic Code: CR200X Program to Measure 3 CS650

Probes

Public CS650(18)

DataTable (CS650,1,-1)
DataInterval (0,60,Min)
Average (18,CS650(),False)
EndTable

BeginProg
Scan (15,Min)

SWBatt (1 ) 'Apply power to CS650's
Delay (3,sec) 'Warm-up time of 3 seconds

'CS650 #1
SDI12Recorder (CS650(1),"0M3!",1,0)

'CS650 #2
SDI12Recorder (CS650(4),"1M3!",1,0)

'CS650 #3
SDI12Recorder (CS650(7),"2M3!",1,0)

SWBatt (0 ) 'Remove power from CS650's
CallTable CS650 'Call Data Table
NextScan
EndProg

24
