9. wiring for program example 5 – Campbell Scientific CS650 and CS655 Water Content Reflectometers User Manual
Page 31

CS650 and CS655 Water Content Reflectometers
TABLE 6-9. Wiring For Program Example 5
CR10X CS650’s (wiring same for both)
12V
Red
C1
Green
G
Black, Orange, Clear
Code Example 5. Edlog Code: CR10X Program to Measure a Two CS650
Probes on Same Control Port
;{CR10X}
;Inloc labels
;1 VWC ;7 VWC_2
;2 EC
;8 EC_2
;3 Tsoil
;9 Tsoil_2
;4 Ka
;10 Ka_2
;5 PerAvg
;11 PerAvg_2
;6 VR
;12 VR_2
*Table 1 Program
01: 900
Execution Interval (seconds)
1: SDI-12 Recorder (P105)
1: 0
SDI-12 Address
2: 3
Start Measurement (aM3!)
3: 1
Port
4: 1
Loc [ VWC ]
5: 1.0
Multiplier
6: 0.0
Offset
2: SDI-12 Recorder (P105)
1: 1
SDI-12 Address
2: 3
Start Measurement (aM3!)
3: 1
Port
4: 7
Loc [ VWC_2 ]
5: 1.0
Multiplier
6: 0.0
Offset
;Save data hourly
3: If time is (P92)
1: 0
Minutes (Seconds --) into a
2: 60
Interval (same units as above)
3: 10
Set Output Flag High (Flag 0)
4: Set Active Storage Area (P80)
1: 1
Final Storage Area 1
2: 60
Array ID
5: Real Time (P77)
1: 1220
Year,Day,Hour/Minute (midnight = 2400)
6: Average (P71)
1: 12
Reps
2: 1
Loc [ VWC ]
23
