CS650 and CS655 Water Content Reflectometers
TABLE 6-7. Wiring For Program Example 3
CR1000 AM16/32B (2x32 mode) CS650
12V 12V
G GND
C2 RES
C3 CLK
SW12 COM ODD H
C1 COM ODD L
G COM Ground
High Channels 1H – 12H Red
Low Channels 1L – 12L Green
Ground Channels to Left of Low
Channels
Black, Orange,
Clear
Code Example 3. CRBASIC Code: CR1000 Program to Measure 12
CS650 Probes on a AM16/32 Multiplexer
Dim LCount
Public CS650(12,6)
DataTable (DatoutCS650,1,-1)
DataInterval (0,60,Min,2)
Average (72,CS650(),IEEE4,False)
EndTable
BeginProg
Scan (15,Min,0,0)
PortSet(2,1)
'Turn AM16/32 Multiplexer On
Delay(0,150,mSec)
LCount=1
SubScan(0,uSec,12)
PulsePort(3,10000)
'Switch to next AM16/32 channel
SW12 (1 ) 'Apply power to CS650
Delay (0,3,Sec) 'Wait three seconds for probe to warm up
SDI12Recorder (CS650(LCount,1),1,0,"M!",1.0,0)
LCount=LCount+1
SW12 (0)
'Remove power from CS650
NextSubScan
PortSet(2,0)
'Turn AM16/32 Multiplexer Off
Delay(0,150,mSec)
CallTable DatoutCS650
'Call Data Table
NextScan
EndProg
6.6.4 CR10X With a Single CS650 Probe
This Edlog example program measures one CS650 probe on a CR10X every 15
minutes, storing hourly averages of volumetric water content, electrical
conductivity, soil temperature, permittivity, period average, and voltage ratio.
The CS650 has a SDI-12 address of 0. Wiring for the example is shown in
TABLE 6-8.
