CS650 and CS655 Water Content Reflectometers
TABLE 6-8. Wiring For Program Example 4
CR10X CS650
12V Red
C1 Green
G Black, Orange, Clear
Code Example 4. Edlog Code: CR10X Program to Measure a Single
CS650 Probe
;{CR10X}
;Inloc labels
;1 VWC
;2 EC
;3 Tsoil_C
;4 Ka
;5 PerAvg
;6 VR
*Table 1 Program
01: 900
Execution Interval (seconds)
1: SDI-12 Recorder (P105)
1: 0
SDI-12 Address
2: 3 Start Measurement (aM3!)
3: 1 Port
4: 1 Loc [ VWC ]
5: 1.0 Multiplier
6: 0.0 Offset
;Save data hourly
2: If time is (P92)
1: 0
Minutes (Seconds --) into a
2: 60 Interval (same units as above)
3: 10 Set Output Flag High (Flag 0)
3: Set Active Storage Area (P80)
1: 1
Final Storage Area 1
2: 60 Array ID
4: Real Time (P77)
1: 1220
Year,Day,Hour/Minute (midnight = 2400)
5: Average (P71)
1: 6
Reps
2: 1 Loc [ VWC ]
6.6.5 CR10X With 2 CS650 Probes on Same Control Port
This Edlog example program measures one CS650 probe on a CR10X every 15
minutes, storing hourly averages of volumetric water content, electrical
conductivity, soil temperature, permittivity, period average, and voltage ratio.
The first CS650 has a SDI-12 address of 0 and the second has address of 1.
Wiring for the example is shown in TABLE 6-9.
