17 Description of the DTRX324 receiver
For specifications and installation examples refer to the chapters relevant the DTRX324 receiver.
To supply the DTRX324 receiver in a correct way refer to the following scheme:
NB: For any other installation procedure, refer to the DTRX3 receiver description. (positioning device
connection, lens, preset, protocol and baud rate settings, etc.).
17.1 Compatible devices for the use with the DTRX324 receiver
Refer to the following connectable devices:
• Control
keyboards: DCS3, DCS2, DCMT8, DCJ, DCT, DCTEL, DCIR
• Pan & Tilt motors: PTH311/PTH311P, PTH911/PTH911P, NXPTH211
• Communications
controller:
DCMX
• Serial data distributor: DCRE485
Read the instruction manuals for the correct use of the above mentioned devices.
Receiver power supply 24 V~ 50/60 Hz
