Page 21 MNVCDTRX301_0850
15 Dip Switch SW4 and SW6 configuration tables
SW6
Dip Position Function
1 ON Pelco D protocol
1 OFF Videotec or MACRO protocols (setting the dip 8 of SW4)
2 3 4 No action No one
SW4
Dip Position Function
1 2 OFF OFF 9600 baud* (Videotec and MACRO), 2400 Pelco D
1 2 ON OFF 300 baud Videotec, 38400 baud MACRO, 4800 baud Pelco D
1 2 OFF ON 1200 baud (Videotec and MACRO), 9600 baud Pelco D
1 2 ON ON 19200 baud (Videotec, MACRO and Pelco D)
3 OFF Alarms not used*
3 ON Alarms used
4 OFF Alarms N.C.*
4 ON Alarms N.O.
5 OFF --
5 ON Alarms on Aux4
6 OFF --
6 ON Aux3 and Aux4 at release
7 OFF --
8 ON** Standard Videotec protocol ****
8 OFF*** MACRO protocol **** (DCJ, DCT, DCTEL and DCIR)
NOTES:
* Default
setting.
** Compatible with keyboards DCS3, DCS2 and DCMT8 (DCJ, DCT, DCTEL and DCIR with standard
Videotec protocol).
*** Compatible with keyboards DCJ, DCT, DCTEL and DCIR with MACRO protocol.
*** Can only be selected if switch 1 of SW6 is OFF
16 Technical features
Power supply: 230 V~ 50 Hz
Consumption 60 W
Max switching power: 100 W
Power supplied to the positioning device 24/230 V~ 50 Hz selectable
Power supplied to the wiper 24/230 V~ 50 Hz selectable
Power supplied to the washer 230 V~ 50/60 Hz selectable
Power supplied to the lens 3 V = ÷ 12 V= (max 100 mA)
Fuses
F2: 1 A F 250 V
F5: 2.5 A F 250 V
Operating temperature 0 - 50°C
Dimensions 337 x 237 x 128 mm
Weight (net): 3,6 kg
