EN 11
ENGLISH
Controls, Connectors and Indicators
The remote control keys with the same names as the keys
on the main system function in the same way as the keys
on the main system. The keys marked * are available only
on the remote control unit.
MUTE MODE
AUTO/MONO DIRECT
TUNER CD D.AUDIO
MD PHONO TAPE
AUX D-IN 1 D-IN 2 DIMMER
TIMER
SLEEP
TIME/PTY
CLEAR DISPLAY
P.MODE RANDOM REPEAT
OPEN/
CLOSE
FOLDER BASS TREBLE
BALANCE
PREV. NEXT
RC-RP0704E
1 PHONO, MD, TAPE, AUX, D-IN 1 and D-IN 2 keys*
(See page 14.)
Press one of these keys to select the desired external input
source.
2 Numeric keys* (See pages 18, 25 and 28.)
{ When the [TUNER] input is selected: Press the keys for
Preset Call (recalling a preset radio station).
{ When the [CD] input is selected: Press to select a track
number or program number.
3 P.MODE key* (See page 28.)
Press to switch between the track mode (normal playback)
and program playback (playback by reordering tracks).
RANDOM key* (See page 31.)
Press for random playback (playback in a random order) of CD.
REPEAT key* (See page 30.)
Press for repeat playback (repeating a track(s)) of CD.
4 Setup mode-related keys
(See pages 13, 22, 24, 32, 33 and 36.)
MODE key*
Press for various setups including auto presetting of radio sta-
tions and timer setting.
Multi-control ( %, fi, @, #) keys*
Press to select a setup item.
ENTER key*
Press to enter a setup.
5 AUTO/MONO key (See page 23.)
{ Wh en the [TUNER] input is selected: Press to switch
between auto tuning (auto/stereo reception) and mono
tuning (manual/monaural reception).
6 TUNER/BAND key (See page 23.)
Press to select the [TUNER] input.
{ When the [TUNER] input is selected: Press to switch the
receiving radio band (FM/AM).
CD 6 key (See page 18.)
Press to select the [CD] input.
{ When the [CD] input is selected: Press to switch the play
and pause modes.
D.AUDIO 6 key (See page 20.)
Press to select the [D.AUDIO] input.
{ When the [D.AUDIO] input is selected: Press to switch
the play and pause modes.
7 key (See pages 18 and 21.)
{ When the [CD] or [D.AUDIO] input is selected: Press to
stop playback.
{ In standby mode: Press to display the time of the day or
day of the week.
7 P.CALL/ 4, ¢ keys (See pages 18, 21 and 25.)
{ When the [TUNER] input is selected: Press for Preset Re-
call (recalling a preset radio station).
{ When the [CD] input is selected: Press to skip a track.
{ When the [D.AUDIO] input is selected: Press to skip or
search (by fast forward or fast reverse) a track.
TUNING/ 1, ¡ keys (See pages 19 and 23.)
{ When the [TUNER] input is selected: Press to select a
frequency.
{ When the [CD] input is selected: Press to search a track
(by fast forward or fast reverse).
8 BASS %, fi keys* (See page 15.)
Press to adjust the bass (low-frequency) level.
TREBLE %, fi keys* (See page 15.)
Press to adjust the treble (high-frequency) level.
9 Power key (See page 14.)
Press to switch the power mode of the system between ON
and standby.
Remote control unit
Continued to next page
