39
Telephone: (508) 678-9000 Fax: (508) 678-9447
Illus. No. Part No. Qty. Description
1 150300 4 #10-16 x 1/2” Hex Washer TEK Screw
2 318065 1 Burner Box Clean Out Plate
3 320656 1 Back Plate Cover
4 150302 5 #6 x 3/8” Phillips Pan Head TEK Screw
5 --------- 6 Heating Elements
(refer to Electric Oven Component Chart on page 47)
6 319703 1 Hi-Limit Bracket
7 151001 2 #8-32 Pal Nut
8 130400 1 290º Thermostat
9 320653 1 ADE-330/ADE-320 Stainless Steel Electric Reflector
10 318651 1 ADE-330/ADE-320 Oven Wire Bracket
11 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
12 137027 1 Strain Relief
13 320655 1 ADE-330/ADE-320 Contactor Bracket
14 152014 1 1/4-20 Free Spin Wash Nut
15 121010 1 L-70 Terminal Lug
16 112075 1 “GROUND HERE” Label
17 --------- 1 Oven Contactor
(refer to Electric Oven Component Chart on page 47)
18 824828 1 RC Network with Connectors
19 121011 * Bus Bar
20 153009 15 #10 Star Washer
21 150212 15 #10-32 x 5/16” Phillips Pan Head Stainless Steel Screw
22 --------- * Terminal Lug
(refer to Electric Oven Component Chart on page 47)
23 150309 4 #10-16 x 1/2” Hex Head TEK Crimptite Screw
* As required.
Electric Oven Assembly
