OPL Microprocessor (DMC) Control Panel Assembly
Illus. No.
Part No.
Qty.
Description
1
112559
1
OPL Keyboard (touch pad) Label ONLY
2
824009
1
OPL Control Panel Assembly Complete - 24 VAC
(includes illus. nos. 1 through 5 and 7)
824011
1
OPL Control Panel Assembly Complete with Battery Option - 24 VAC
(includes illus. nos. 1 through 5 and 7)
882232
1
OPL Control Panel ONLY
3
137234
1
Phase 5 Dual Microprocessor Controller (DMC) ONLY
824998
1
Phase 5 Battery Clip...Not Illustrated
4
153010
2
#6 Star Washer
5
150005
2
#6-32 x 1/4” Phillips Round Head Machine Screw
6
150309
1
#10-16 x 1/2” Hex Head TEK Crimptite Screw
7
136048
2
1/8-Amp (Slo-Blo) Fuse
