Basket (tumbler) bearing assembly – American Dryer Corp. 24 VAC Phase 5 AD-320 User Manual
Page 31
29
Telephone: (508) 678-9000
Fax: (508) 678-9447
Illus. No.
Part No.
Qty.
Description
1
880203
1
1-3/8” Flange Bearing ONLY
2
153005
4
3/8” Lock Washer
3
152005
4
3/8-16 Hex Nut
4
882544
1
Pillow Block Bearing Assembly Complete
(includes illus. nos. 4 through 14 and 17)
882545
1
Bearing Assembly Complete (for models mfd. with rotational sensor)
(includes illus. nos. 4 through 17)
882542
1
Bearing Support ONLY
882543
1
Bearing Support ONLY (for models mfd. with rotational sensor)
5
880202
1
1-3/8” Pillow Block Bearing ONLY
880779
1
1-3/8” Pillow Block Bearing (for models mfd. with rotational sensor)
6
150601
2
3/8-16 x 2” Hex Bolt
7
153004
8
3/8” Flat Washer
8
153005
2
3/8” Lock Washer
9
152005
2
3/8-16 Hex Nut
10
154326
2
5/16-24 x 3/8” Setscrew (black)
11
152004
4
5/16-18 Hex Nut
12
150621
2
5/16-18 x 1-1/2” Tap Bolt
13
153002
4
5/16” Lock Washer
14
150501
4
5/16-18 x 3/4” Tap Bolt
15
102120
1
Sintered 8 Magnet
16
824807
1
Rotational Sensor Assembly (for models mfd. with rotational sensor)
17
150610
2
5/16-18 x 1-1/2” Allen Setscrew
Basket (Tumbler) Bearing Assembly
