Dmc control box assembly – American Dryer Corp. 24 VAC Phase 5 AD-320 User Manual
Page 21

19
Telephone: (508) 678-9000
Fax: (508) 678-9447
Illus. No.
Part No.
Qty.
Description
6*
136008
**
3-Position Fuse Block
7
150002
1
#6-32 x 1” Round Head Machine Screw
8*
136057
3**
1/2-Amp (Slo-Blo) Fuse ONLY
9
150002
2
#6-32 x 1” Round Head Machine Screw
10
120715
1
30-Position Terminal Block
11
151000
2
#6-32 Pal Nut
12
150103
4
#8-32 x 3/4” Phillips Round Head Machine Screw
13
132451
2
2-Pole Contactor
14
151001
4
#8-32 Pal Nut
15
824828
2
RC Network with Connectors
16
122626
1
15-Pin Socket Connector ONLY
17
122705
9
Socket Terminal ONLY
18
122704
9
Pin Terminal ONLY
19
122625
1
15-Pin Connector ONLY
137025
1
6/15-Position Strain Relief...Not Illustrated
20
122631
1
6-Pin Socket Connector ONLY
21
122705
6
Socket Terminal ONLY
22
122704
6
Pin Terminal ONLY
23
122630
1
6-Pin Connector ONLY
137025
1
6/15-Position Strain Relief...Not Illustrated
24
150309
1
#10-16 x 1/2” Hex Head TEK Crimptite Screw
25
121010
1
L-70 Terminal Lug
26
122626
1
15-Pin Socket Connector ONLY
27
122705
7
Socket Terminal ONLY
28
122704
7
Pin Terminal ONLY
29
122625
1
15-Pin Connector ONLY
137025
1
6/15-Position Strain Relief...Not Illustrated
30
121494
10
Push-Mount Wire Tie
--
122801
1
Pin/Socket Extraction Tool...Not Illustrated
--
122800
1
Microprocessor (female) Pin Extraction Tool
*
Check fuse rating for verification.
** For 120 volt application the quantity is 1. For 208/240 volt application the quantity is 2.
DMC Control Box Assembly
