AD-330 Locking Lint Drawer (Basket) Assembly
Illus. No. Part No. Qty. Description
1 883397 1 AD-330 White Locking Lint Drawer (basket) Assembly
Less Lock and Key
(includes illus. nos. 1 and 2)
883398 1 AD-330 Ivory Locking Lint Drawer (basket) Assembly
Less Lock and Key
(includes illus. nos. 1 and 2)
883399 1 AD-330 Coral Blue Locking Lint Drawer (basket) Assembly
Less Lock and Key
(includes illus. nos. 1 and 2)
883400 1 AD-330 Black Locking Lint Drawer (basket) Assembly
Less Lock and Key for Stainless Steel Models ONLY
2 117604 3 Neoprene Sponge Tape (sold by the foot)
3 --------- 1 Temperature Sensor Bracket
(refer to Temperature Sensor Probe Assembly on page 27)
4 --------- 1 Lint Drawer (basket) Switch
(refer to AD-330 Lint Drawer [Basket] Switch Assembly on page 30)
5 160038 1 Lint Drawer Lock Assembly (keyed to number XX4451)
160140 1 Key ONLY (key number XX4451)
160034 1 Cam ONLY
