DME VCTB-4000 User Manual
Page 10
D-M-E Company
VCTB-4000
Page 10
ED-0109-OT-024-( Preliminarry Rev E)
Instructions Installation Instructions for the
VCTBA-01 Valve Gate Control Interface Accessory
VCTBA01 ACCESSORY: VCTB4000 TO POLIVALVE 2X8 CONNECTOR
( Cable is wired for 8 zones, but only controls 4 zones when connected to the VCTB4000 as shown below )
VCTBA01 shown with 2x8 Polyvalve Assembly VCTBA01 shown connected to VCTB4000 & Polyvalve Assemby
