emc-3 Controller Module
User Guide – Rev A
Appendix C, Settings and Limits
EE-Memory Variable Min Max Description
Coolant_Start_Temp 0 Max - 1 Start Temp for J1939 Coolant
Temperature
Coolant_Max_Temp Start + 1 150 100% Demand for J1939
Coolant Temperature
Coolant_OverTemp Max + 1 Max + 30 Over Temp Trip Point for J1939
Coolant Temp
Manifold_Start_Temp 0 Max - 1 Start Temp for J1939 Manifold
Temperature
Manifold_Max_Temp Start + 1 150 100% Demand for J1939
Manifold Temperature
Manifold_OverTemp Max + 1 Max + 30 Over Temp Trip Point for J1939
Manifold Temp
TransOil_Start_Temp 0 Max - 1 Start Temp for J1939
Transmission Oil Temperature
TransOil_Max_Temp Start + 1 150 100% Demand for J1939
Transmission Oil Temperature
TransOil_OverTemp Max + 1 Max + 30 Over Temp Trip Point for J1939
Transmission Oil Temp
Thermistor1_Start_Temp 0 Max - 1 Start Temp for Thermistor 1
Thermistor1_Max_Temp Start + 1 150 100% Demand for Thermistor 1
Thermistor1_OverTemp Max + 1 Max + 30 Over Temp Trip Point for
Thermistor 1
Thermistor2_Start_Temp 0 Max - 1 Start Temp for Thermistor 2
Thermistor2_Max_Temp Start + 1 150 100% Demand for Thermistor 2
Thermistor2_OverTemp Max + 1 Max + 30 Over Temp Trip Point for
Thermistor 2
Thermistor3_Start_Temp 0 Max - 1 Start Temp for Thermistor 3
Thermistor3_Max_Temp Start + 1 150 100% Demand for Thermistor 3
Thermistor3_OverTemp Max + 1 Max + 30 Over Temp Trip Point for
Thermistor 3
Auto_Rev_Interval_Minutes 0 or 2 500 8 Hours Max
Reverse_Cycle_Seconds 0 60 1 minute
Bank_1_Off_DYCY 0 Start - 1 DYCY to ensure fan is Off
Bank_1_Start_DYCY 0 Max - 1 DYCY for Minimum Fan Speed
Bank_1_Max_DYCY Start + 1 100 DYCY for Maximum Fan Speed
Bank_1_Rev_DYCY 0 100 DYCY for Reverse Fan
Operation
Bank_2_Off_DYCY 0 Start - 1 DYCY to ensure fan is Off
Bank_2_Start_DYCY 0 Max - 1 DYCY for Minimum Fan Speed
Bank_2_Max_DYCY Start + 1 100 DYCY for Maximum Fan Speed
