emc-3 Controller Module
User Guide – Rev A
emc-3 Configuration Message
Multiplex Data Set Table
1st Data Set
Byte 1
Mux Control 01h
Byte 2 Coolant Start Temp
Byte 3 Coolant Max Temp
Byte 4 Coolant Over Temp
Byte 5 Manifold Start Temp
Byte 6 Manifold Max Temp
Byte 7 Manifold Over Temp
Byte 8 Write Enable (FF01 Only)
2nd Data Set
Byte 1
Mux Control 02h
Byte 2 Trans Oil Start Temp
Byte 3 Trans Oil Max Temp
Byte 4 Trans Oil Over Temp
Byte 5 Thermistor 1 Start Temp
Byte 6 Thermistor 1 Max Temp
Byte 7 Thermistor 1 Over Temp
Byte 8 Write Enable (FF01 Only)
3rd Data Set
Byte 1
Mux Control 03h
Byte 2 Thermistor 2 Start Temp
Byte 3 Thermistor 2 Max Temp
Byte 4 Thermistor 2 Over Temp
Byte 5 Thermistor 3 Start Temp
Byte 6 Thermistor 3 Max Temp
Byte 7 Thermistor 3 Over Temp
Byte 8 Write Enable (FF01 Only)
4th Data Set
Byte 1
Mux Control 04h
Byte 2 Bank 1 Off DYCY
Byte 3 Bank 1 Start DYCY
Byte 4 Bank 1 Max DYCY
Byte 5 Bank 1 Rev DYCY
Byte 6 Bank 1 Number of Fans
Byte 7 Bank 1 Fans Idle Enable
Byte 8 Write Enable (FF01 Only)
5th Data Set
Byte 1
Mux Control 05h
