Analog Specifications
Analog Output Drift 10ppm/Degree F (18ppm/DegreeC)
Analog Output
Loading
Voltage Output Minimum Load Resistance: 2Kohm
Current Output Maximum Load Resistance: (Vin - 2)/0.02
Output Current: Guaranteed 6mA minimum for voltage units
Analog Ripple <1 mV maximum (position output)
Update Time 1mS (stroke lengths 1" to 50")
2mS (stroke lengths 51" to 100")
3mS (stroke lengths 101" to 150")
4mS (stroke lengths 151" to 168")
Position Output 0 - 10 VDC, 16 Bits (65,535) resolution 4 - 20mA, 16 Bits (65,535) resolution
CE Approved with Connector Option "S" Only
Output May Vary by 0.1% when Subjected to Severe Levels of Electrical Noise
Digital Specification
Update Time Controller Dependent
Digital Output CP RS-422 Control Pulse
VP RS-422 Pulse Width Modulated
RS RS-422 Start/Stop
(BCD, Binary, or Gray Code Outputs
available from 2120 Interface Module.)
Quadrature Specification
Digital Output 1) Quadrature A: RS-422 differential
2) Quadrature B: RS-422 differential
3) Zero (index) position: RS-422 differential
maximum 5V, minimum 2V into a 50Ω load
Digital Input 1) Zero position set: 5-30V Source or Sink
2) Burst mode input: 5-30 Source or Sink
Input impedance: 5KΩ
Sink threshold: Input < 0.41 x VPS. (Power Supply Voltage)
i.e.: 0.41 x 24VDC Power Supply = <9.84VDC
Source threshold: Input > 0.41 x VPS. (Power Supply Voltage)
i.e.: 0.41 x 24VDC Power Supply = >9.84VDC
TTL threshold: Input > 2.1V
