Appendix C: Specifications
General Specifications
Rod End 316 Stainless Steel, 0.405" (10.29 mm) outer diameter
Mounting Hex 316 Stainless Steel, 1.75" (44.45 mm) across flats
Mounting Threads 3/4-16 UNF-2B x 1.00" (25.4 mm) with ESNA Jam Nut and O-ring seal
Head Assembly Thick Wall Aluminum Cover with Viton O-ring Standard Gasket Seal at the Base and
Connector Exit, NEMA 4 (Type 6 optional, consult factory).
Connector 1/4 turn MS-Style Standard (quick connect/disconnect) Connector. Consult factory for
other options
Displacement Up to 168"
Electromagnetic
Compatibility
IEC 801-2, Level 3 (Electrostatic discharge requirements)
IEC 801-4, Level 3 (Electrical fast transient/burst requirements)
Dead Band 2.50" (63.5 mm) standard
Null Zone 2.00" (50.8 mm) standard
Head Enclosure 3" (76.20 mm) high with 1.75" (44.45 mm) diameter; hex and cover are NEMA 4
Electrical Specifications
Input Voltage
Unipolar
Bipolar
Analog: 13.5 to 26.4 VDC
Digital: 13.5 to 26.4 VDC
±15 VDC ±10% (Digital Units Only)
Quadrature: 11 to 28 VDC
Current Draw
Unipolar
Bipolar
(Digital LDT Only)
3 watts maximum, 200mA at 15 VDC (1 Watt, Typical)
100mA maximum @ +15 VDC, 100mA maximum @ -15 VDC
Nonlinearity Less than +/- 0.05% *
Repeatability +/–0.001% of full stroke or 0.002" (0.0254 mm), whichever is greater.
Hysteresis +/- 0.02% *
Temperature
Coefficient LDT
Less than 0.00011 in./Degree F + [3 PPM/Degree F/in. of Full Stroke] (Less than 0.00503
mm/Degree C + [5.4 PPM/Degree C/mm of Full Stroke]).
Operating
Temperature
Head (Electronics)
Guide Tube
-40° to +158° F ( -40° to +70° C)
-40° to +220° F (-40° to +105° C)
Storage Temperature -40° to 185° F (-40° to +85° C)
Operating Pressure
5000 psi Operational, 10,000 psi Spike
Shock & Vibration
Vibration
Shock
30 Grms.
2000 G.
* Specifications are based on a typical 36" stroke length.
