4.7: 952 QD Frequency
Frequency or Pulse Rate
Selecting the proper frequency in the part number
and your controller is very important. The internal
clocks inside of the 952QD interrogates the LDT
and transmits the incremental pulses at a fixed rate
of speed. The frequency or pulse rate of the 952QD
is factory set to 10KHZ - 1.00MHZ, consult part
numbers for your model. The input to the PLC or
display will determine the frequency needed.
Example: If your PLC High Speed counter card or
display accepts a 1MHZ encoder input the choices
are:
F1 = 10KHZ
F2 = 25KHZ
F3 = 50KHZ
F4 = 75KHZ
F5 = 100KHZ
F6 = 150KHZ
F7 = 250KHZ
F8 = 500KHZ
F9 = 1.00MHZ
NOTE: If your controller’s maximum input frequency
falls between two available frequencies, choose the
lower frequency.
