B.2: Digital Part Numbering

952VP

0120

CP = Control Pulse

VP = Variable Pulse

RS = RS422 Start/Stop Pulse

Interrogation Mode (with VP only)

I = Internal Interrogation

E = External Interrogation

Stroke in Inches

Insert stroke in inches to 0.1 inch. Enter as a four-place

number.

Example: 12.0 in stroke entered as 0120. To

convert a metric stroke in millimeters, multiply millimeter

value by 0.03937 to arrive at inch value.

Null Zone

X = Standard 2 inch Null

N _= Insert non-standard Null over 2 inches

Dead Zone

X = Standard Dead Zone of 2.5 inches

D _= Insert non-standard Dead Zone over 2.5 inches

* If option E (environmental connector) is selected, mating connector

and/or pigtail must be ordered separately.

NOTE 1: On unsupported stroke

lengths greater than 4 feet, rod support bracket(s) and a special magnet

should be used.

NOTE 2: Specify as magnet separate line item (standard

magnet is SD0400800).

WARNING: Not for use with a GEMCO interface.

001

Recirculations Required (with VP only)

001 (standard) to 127

Connector Style

E = Environmental MS Connector*

C _= Potted Pigtail Cable Assembly. Insert Pigtail length in feet.

T = Threaded Metal Connector (fits MTS - RB on Tempo II

or III) (RS and VP only)

Q = Bayonet Style Connector (fits MTS - RC on Tempo II

or III) (RS and VP only)

M = 1/4 Turn Quick Disconnect (fits MTS - MS on Tempo II

or III) (RS and VP only)
