B.3: Quadrature Part Numbering
952QD 0120
BlueOx with
Quadrature Output
Stroke in Inches
Insert stroke in inches to 0.1 inch. En-
ter as a four-place number. Example:
12.0 in stroke entered as 0120. To
convert a metric stroke in millimeters,
multiply millimeter value by 0.03937 to
arrive at inch value.
X X 1000
Null Zone
X = Standard 2 inch Null
N _= Insert non-standard Null over 2
inches.
Dead Zone
X = Standard Dead Zone of 2.5 inches
D _= Insert non-standard Dead Zone over 2.5 inches
Connector Style
E = Environmental MS Connector*
C _= Potted Pigtail Cable Assembly. Insert Pigtail length
in feet.
E E F7 M1 D N
Output Resolution
Cycles per inch, maximum internal resolution is 0.001 inches
1000 standard (available range is 0001 through 9999)
Input Type
E = Sinking (typically used with sourcing output type)
C = Sourcing (typically used with sinking output type)
T = TTL Level
Quadrature Cycle Output Frequency Range
F1 = 10 KHz F2 = 25 KHz F3 = 50 KHz F4 = 75 KHz
F5 = 100 KHz F6 = 150 KHz F7 = 250 KHz F8 = 500 KHz F9 = 1.00 MHz
Output Mode
M1 = X1 quadrature, Consult factory for other output modes.
Zero Offset Storage
V = Volatile (non retentive)
N = Nonvolatile (retentive, 100,000 storage cycles maximum).
Output Drivers
D = Differential RS422 line driver, TTL compatible
L = Differential line driver 10 - 30 VDC, V out = V in (LDT Power) -1 volt
X
Options
X = None
* If option E (environmental connector) is selected,
mating connector and/or pigtail must be ordered separately.
NOTE: Consult factory for
custom configurations.
