Appendix B: Ordering Information
B.1: Analog Part Numbering
* If option S or E (environmental connector) is selected,
mating connector and/or pigtail must be ordered
separately. NOTE 1: On unsupported stroke lengths
greater than 4 feet, rod support bracket(s) and a special
magnet should be used. NOTE 2: Specify magnet as
separate line item (standard magnet is SD0400800).
952A
Analog BlueOx
0120 X E X
Stroke in Inches
Insert stroke in inches to 0.1 inch. Enter as a four-place number.
Example: 12.0 in stroke entered as 0120. To convert a metric stroke in
millimeters, multiply millimeter value by 0.03937 to arrive at inch value.
On differential output units (D0 or D1) the active measuring range will
be 2.5” less than the specified stroke due to the 2.5” magnet to magnet
separation distance requirement.
Null Zone
X _= Standard 2 inch Null
N = Insert non-standard Null over 2 inches
Dead Zone
X = Standard Dead Zone of 2.5 inches
D _= Insert non-standard Dead Zone over 2.5 inches
Connector Style
S = Standard 12mm 5 pin Euro Connector ( CE Approved )
E = Environmental MS Connector*
C _= Potted Pigtail Cable Assembly. Insert Pigtail length in feet.
T = Threaded Metal Connector (fits MTS® - RB on Tempo II TM or III)
Q = Bayonet Style Connector (fits MTS® - RC on Tempo II TM or III)
M = 1/4 Turn Quick Disconnect (fits MTS® - MS on Tempo II TM or III)
Consult factory for other connector options.
Output Type
V0 = 0 - 10 VDC
V1 = 10 - 0 VDC
C4 = 4 - 20mA
C2 = 20 - 4mA
D0 = Differential 0 - 10 VDC*
D1 = Differential 4 - 20mA *
*Analog differential output is the difference between two magnets.
Minimum distance is 2.5”.
V0
MTS® is a Registered Trademark of MTS Systems Corp.
