952 cp, rs, vp wiring – AMETEK 952 BlueOx LDT User Manual
Page 14
14
1080 N. Crooks Road • Clawson, MI 48017 • 800.635.0289 • 248.435.0700 • Fax 248.435.8120 • www.AMETEKAPT.com
Figure 3-7: 952CP, VP, and RS Wiring Drawing
3.9: 952 CP, RS, VP Wiring
WHITE
BLUE
BROWN
GRAY
RED
BLACK
+GATE
-INTERROGATION
-GATE
+INTERROGATION
+15 TO +26 VDC
POWER SUPPLY
ORANGE
NO CONNECTION
PINOUT FOR STANDARD
CIRCULAR CONNECTOR
AT TRANSDUCER HEAD
GREEN
YELLOW
PURPLE
NO CONNECTION
NO CONNECTION
-15 VDC FOR BIPOLAR
POWER SUPPLY
POWER SUPPLY*
PIN-B
PIN-C
PIN-K
PIN-E
PIN-F
PIN-A
PIN-G
PIN-D
PIN-H
PIN-J
COMMON
*For unipolar power supply, it is recommened
to connect this wire to power supply common
Drawing No. Rev.
E0230900 0
