Figure 2-2: Mounting LDT in a Hydraulic Cylinder
Figure 2-3: Port Detail (SAE J1926/1)
OPTIONAL ROD BUSHING
MAGNET SPACER
O-RING SEAL
CABLE NUT
STANDARD 4-HOLE MAGNET
0.5" BORE MINIMUM
A
.004 A
.008 A
125
125
PITCH
DIA. REF.
SEE NOTE 4
.094 MAX.
R.015
MAX.
.008
.004
R
RECOMMENDED
MIN. SPOTFACE
DIAMETER
SEE NOTE 1
1.18
.500
.866
.813
+/-.002
45
15
.106
+/-.008
1.250
SEE NOTE 3
SEE NOTE 4
3/4-16 UNF-2B THREAD
1.100
SEE NOTE 4
MINIMUM
SEE NOTE 2
