CONFIGURE SECOND ANALOG INPUT
MNEMONIC PARAMETER USER SETTING
OPEr Second Input Operating Mode
root Second Input Square Root Linearization
dPt2 Second Input Decimal Point Position
dSP1 Second Input, Display Scale Point 1
INP1 Second Input, Input Scale Point 1
dSP2 Second Input, Display Scale Point 2
INP2 Second Input, Input Scale Point 2
SPtr Local/Remote Setpoint Select Action
OPd2 Secondary PID Output Power Dampening
CONFIGURE VALVE POSITIONER
MNEMONIC PARAMETER USER SETTING
VPS1 Valve Positioner Scale Point 1
VPS2 Valve Positioner Scale Point 2
VUdt Valve Positioner Update Time
VPdb Valve Positioner Deadband
VFAL Valve Positioner Fail Time Alarm
VOPt Valve Positioner Motor Open Transit Time
VCLt Valve Positioner Motor Close Transit Time
VONt Valve Positioner Minimum On Time
CONTROLLER OPERATING MODE
Local or Remote Setpoint ____________________________
Automatic or Manual ____________________________
Auto-tune Invoked at ____________________________
