Configure Module 5 - Secondary Output Parameters (5-O2)
Unit returns to configuration access point if secondary output option is
not installed.
Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
CYC2 Secondary output
cycle time 0 to 250 sec
(2) 0 turns OP2 off.
GAN2 Relative gain 0.0 to 10.0
(1.0) 0.0 places
secondary output
into ON/OFF control
mode and db-2
becomes hysteresis
value.
db-2 Overlap-deadband -999 to 9999
(0.0) Positive value is
deadband. Negative
value is overlap. If
GAN2 = 0, this
parameter is OP2
ON/OFF control
hysteresis.
-43-
