Configure Module 6 - Serial Communications (6-SC)
Unit returns to configuration access point if RS485 serial option is not
installed.
Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
bAUd Baud rate 300 to 9600
(1200) Baud rate of unit must
match connected
equipment.
PArb Parity bit odd, even, no parity
(odd) Parity of unit must
match other equipment.
Add Unit address 0 to 99
(0) For multiple units, each
unit must have a unique
address.
Abr Abbreviated or
full transmission yes/no
(no) Selecting yes, the
controller does not
transmit mnemonics.
PrAt Auto print rate 0 to 9999
(0) 0 disables auto print
function
PoPt Print options yes/no
(no) Selecting yes allows
print options shown
below, to be
programmed.
INP Input Process
Value yes/no
(yes)
SEt Setpoint yes/no
(yes)
OPr % Output Power yes/no
(yes)
Pbd % Proportional
Band yes/no
(no)
INt Integral Time yes/no
(no)
dEr Derivative Time yes/no
(no)
AL1 Alarm 1 yes/no
(no)
Display Parameter
Range and Units
(Factory Setting
Value)
Description/
Comments
AL2 Alarm 2 yes/no
(no)
dEv Deviation From
Setpoint yes/no
(no)
OFP % Output Power Offset yes/no
(no)
r_P Setpoint Ramp Rate yes/no
(no)
Crg Relative Gain yes/no
(no)
Cdb Deadband yes/no
(no)
OSt Output Status yes/no
(no)
rAt Remote Setpoint Ratio yes/no
(no)
bIA Remote Setpoint Bias yes/no
(no)
Pb2 Secondary Proportional
Band yes/no
(no)
It2 Secondary Integral
Time yes/no
(no)
dt2 Secondary Derivative
Time yes/no
(no)
rSP Remote Setpoint yes/no
(no)
SP2 Secondary Directed
Setpoint yes/no
(no)
IN2 Second Analog Input yes/no
(no)
-44-
