Configure Module 3 - Lockout Parameters (3-LC)
Display Parameter
Range and Units
(Factory Setting
Value)
Description/Comments
SP Setpoint
access LOC - lockout
rED - read only
Ent - enter
(Ent) Determines access to
process setpoint.
OP Output power
access LOC - lockout
rED - read only
Ent - enter
(Ent) Determines direct access
to output power. %PW
indicator illuminates when
parameter is selected in
display.
dEv Deviation LOC - lockout
rEd - read only
(rEd) Determines display of
deviation. DEV indicator
illuminates when
parameter is selected in
display.
IN-2 Second Analog
input LOC - lockout
rEd - read only
(rEd) Determines display of
Second Analog input
(Remote Setpoint)
(SEC) illuminates)
bdSP Blank display LOC - lockout
rEd - read only
(rEd) Blanks secondary display.
Code Access code 0 to 250
(0) Refer to front panel
disable section for access
levels.
PId PID values
enable LOC - lockout
rEd - read only
Ent - enter
(LOC) Protected mode lockout.
PId2 Secondary PID
values enable LOC - lockout
rEd - read only
Ent - enter
(LOC) Protected mode lockout.
Cascade only.
Display Parameter
Range and Units
(Factory Setting
Value)
Description/Comments
rtbS Remote Setpoint
Ratio & Bias LOC - lockout
rEd - read only
Ent - enter
(LOC) Remote Setpoint Ratio
and Bias values enable
AL Alarm values
enable LOC - lockout
rEd - read only
Ent - enter
(LOC) Protected mode lockout
ALrS Reset alarms
enable LOC - lockout
ENBL - enable
(LOC) Hidden mode lockout
SPSL Remote/Local
setpoint select
enable LOC- lockout
ENBL - enable
(LOC) Hidden mode lockout
trnF Automatic/Manual
(user) mode
select enable LOC - lockout
ENBL - enable
(LOC) Hidden mode lockout
tUNE Auto-tune enable LOC- lockout
ENBL - enable
(LOC) Hidden mode lockout
