APPENDIX “F”-USER PARAMETER VALUE CHART
UNIT NUMBER
MNEMONIC PARAMETER USER SETTING
SP Setpoint
OPOF Output Power Offset
OP Output Power
ProP Proportional Band
Intt Integral Time
dErt Derivative Time
SP-2 Internal Cascade Directed Setpoint
Pb-2 Proportional Band #2 (secondary)
It-2 Integral Time #2 (secondary)
dt-2 Derivative Time #2 (secondary)
rtio Remote Setpoint Ratio
bIAS Remote Setpoint Bias
AL-1 Alarm 1
AL-2 Alarm 2
CONFIGURE INPUT
MNEMONIC PARAMETER USER SETTING
tYPE Input Type
dCPt Decimal Point
root Square Root Linearizing
rnd Rounding Increment
FLtr Digital Filtering
dSP1 Display Value 1
INP1 Signal Input Value 1
dSP2 Display Value 2
INP2 Signal Input Value 2
SPLO Setpoint Lower Limit
SPHI Setpoint Upper Limit
SPrP Ramp Rate
InPt User Input
CONFIGURE OUTPUT
MNEMONIC PARAMETER USER SETTING
CYCt Cycle Time
OPAC Control Action
OPLO Output Power Lower Limit Range
OPHI Output Power Upper Limit Range
OPFL Input Overdrive Power Preset
OPdP Output Power Dampening
CHYS ON/OFF Control Hysteresis
tcod Auto-Tune Dampening Code
ANAS Linear Output Assignment
ANLO Linear Output Scale Value
ANHI Linear Output Scale Value
ANdb Linear Output Deadband
ANut Linear Output Update Time
-81-
