WIRING
WIRING CONNECTIONS
All conductors should meet voltage
and current ratings for each terminal.
Also, cabling should conform to
appropriate standards of good installation,
local codes and regulations and be
suitably rated for the temperatures of the
environment to which it is being installed.
When wiring the module, use the numbers
on the label to identify the position
number with the proper function. Strip
the wire, leaving approximately 1/4" (6
mm) of bare wire exposed. Insert the wire
into the terminal, and tighten.
Terminals 13 to 18
Terminals 7 to 12
Terminals 1 to 6
Terminals 19 to 24
(GMP2 Only)
TC/RTD+
INPUT COM.
4-20 mA
0-10 V
N/C
RTD +EXE
1
3
2
5
4
6
SENSE
SENSE
EXC./
JUMPER
6
5
4
3
2
1
0-10 V
4-20 mA
N/C
TC/RTD+
INPUT COM.
RTD +EXE
+
6
5
4
3
2
1
0-10 V
4-20 mA
N/C
TC/RTD+
INPUT COM.
RTD +EXE
LOAD
POWER
+
+
_
_
6
5
4
3
2
1
0-10 V
4-20 mA
N/C
TC/RTD+
INPUT COM.
RTD +EXE
VDC-
VDC+
12
11
10
9
8
7
HCM (OPT)
HCM (OPT)
OP2 COM
OP1 COM
OP1 +
OP2 +
Heater Circuit
AC
RTD
Heater Current Monitor
Voltage
GMP1 INPUT CONNECTIONS
